1800 FOG COP
1800 FOG COP
Fog Cop EASY is very fast in fog emission and produces very dense and long-lasting fog while it leaves no residual after fog-shooting. Its single-use fog cylinders are very easy to change and produce 200m3 of fog in just 18 seconds. A great advantage of EASY fogging systems is the possibility to connect them to any alarm system. They also operate with very low power consumption. Fog fluid is certified and is not dangerous for people or animals. EASY comes at a very competitive price.
| Dimension : | 395X200X272 |
| Colour : | White, Grey |
| Standard working time without main power : | about 1 hours |
| Reaction time from alarm signal : | 1 sec |
| Heat up time from cold : | 40 minutes |
| Quantity of fog released in one shoot : | Setted by choosing fog tank capacity (50 m3, 100 m3, 150 m3) |
| Mounting : | Vertical straight |
| Anti tampering : | Yes |
| Fog generator : | Alluminium fog generator |
| Continuous release each fog cylinder Single shoot : | full tank |
| Total fog ejection in one shoot : | Up to 200 m3 |
| Fog tank : | 50 m3, 100 m3, 150 m3 single use cylinders |
| Temperature controls : | thermocouple + 2 thermostat |
| Fog speed ejection : | Fast up to 20 m3 sec |
| Power supply: | 220 V |
| Average power consumptions: | 40 W |
| Max power : | 220 V AC 0,3 kW |
| Input : | Arming and shooting |
| Backup battery on board : | yes |
| Complies with European CE and EMC: | yes |
| Fog fluid is certified as not dangerous: | yes |
| Meets European standard specifications: | yes |
 FOG COP EASY |
 FOG COP SMART 1C |
FOG COP SMART 2C |
FOG COP SLIM |
 FOG COP EXTREME |
|
|---|---|---|---|---|---|
| GENERAL SPECIFICATIONS | Time shoot | Time shoot | Time shoot | Time shoot | Time shoot |
| Weight of the fog machine | About 10 kg | About 10 kg | About 11 kg | About 15 kg | About 22 kg |
| Weight in the packaging | About 11 kg | About 12 kg | About 13 kg | About 15 kg | About 22 kg |
| Units on one pallet 100X120 | 24 | 30 | 30 | 12 | 24 |
| Dimension of the machine | 39,5X20,0Xh27,2 | 26,5X19,0Xh34,5 | 26,5X19,0Xh34,5 | 30,5X19,0Xh39,0 | 30,0X34,5Xh42,5 |
| Dimension of packaging | 37,0X25,0Xh47,0 | 32,0X25,0Xh43,0 | 32,0X25,0Xh43,0 | 37,0X25,0Xh47,0 | 51,0X39,0Xh52,5 |
| Colours | White/grey | White/optional 10 colors | White/optional 10 colors | White/optional 10 colors | dark grey |
| Standard working time without main power | About 1 hours | About 2 hours | About 2 hours | About 2 hours | over 2,5 hours |
| Heat up time from cold | 40 Minutes | 40 minutes | 40 minutes | 1 hours | 2,30 hours |
| Mounting vertical straight or corner | yes | yes | yes | yes | yes |
| Serial port for monitoring | yes | yes | yes | yes | yes |
| FOG GENERATOR | |||||
| Max fog release in a single shoot | up to 200 m3 | up to 300 m3 | up to 300 m3 | up to 600 m3 | up to 1800 m3 |
| Max seconds of fog release in a single shoot | 18 sec | 15 sec | 15 sec | 30 sec | 60 sec |
| Max tot emission with full fog tanks | 200 m3 | 600 m3 | 1200 m3 | 1500 m3 | 1800 m3 |
| Number of Cylinders | 1 | 1 | 2 | 2 | 2 |
| Fog tank capacity | 1 X 500 ml | 1 X 400 ml | 2 X 400 ml | 1 X 500 ml | 2 X 600 ml |
| Shooting specification | setting in seconds | setting in seconds | setting in seconds | setting in seconds | setting in seconds |
| Cylinder model | A 01 | A 03 | A 03 | A 02 | A 01 |
| Cylinder included | 1 | 1 | 2 | 2 | 2 |
| Doubble fog tank advantage | no | no | yes | yes | yes |
| ELECTRICAL SPECIFICATIONS | |||||
| Power supply | 220/110 V | 220/110 V | 220/110 V | 220/110 V | 220/110 V abd 12V |
| Average power consumptions | ~40 W | ~37 W | ~37 W | ~42 W | ~60 W |
| Optional external battery | no | no | no | no | yes |
| Back up battery | no | no | no | no | yes |
| Optional demo/antirobbery kit | optional | optional | optional | optional | included |
| 12V from alarm system | necessary | necessary | necessary | necessary | not needed |
| STANDARDS | |||||
| Complies with European CE and EMC | yes | yes | yes | yes | yes |
| Fog fluid is certified as not dangerous | yes | yes | yes | yes | yes |
| Meets European standard specifications | yes | yes | yes | yes | yes |
